A buyer can't open the housing on a product listing. An exploded view does it for them: it shows what's inside and why the product is built better than a competitor's.
What it is
The product "flies apart" along one axis — usually vertically — and each part hangs above its place. Dashed lines or a shared axis show where it goes on assembly.
Which products it helps
- Electronics and appliances: housing, board, battery, cooling.
- Products whose value is in how they're built: multi-layer designs, mechanisms, hardware.
- Kits and sets: what's in the box.
- Self-assembly: what it's made of and in what order it goes together.
Labeled, with nothing extra
On a marketplace listing the view is seen on a phone, so there are few assemblies, they're large, and they carry numbers and short names. In technical documentation there can be more parts: there it's studied on a big screen.
Exploded view or cutaway
An exploded view answers "what is it made of". A cutaway answers "how does everything sit inside": channels, layers, flows. For a boiler or a multi-layer design a cutaway is more useful; for a set of parts, an exploded view.
What an exploded view takes
- The product's composition: a CAD model or an assembly drawing. Without them, a disassembled sample or detailed photos of the parts. More in What materials a 3D artist needs.
- Which assemblies to show and which to merge: that's the client's call — you know what matters to the buyer.
- Part names and, if needed, short benefit labels.
- Where the view will live: a listing, a website, a manual. That decides the number of parts and the format.
What it looks like in practice
- HouseGuru: exploded views breaking down how products are built, for marketplace listings.
- FPV FRAME: exploded views of drone frames with the parts taken apart.
- SibMaster: technical cutaways of boilers showing the internals — the grate, the gas channels, the water circuits.
Common mistakes
- Spreading out all forty parts: on a phone it's a mess.
- Parts flying in every direction with no shared axis: it's unclear what goes where.
- Not sending the product's composition and expecting the "insides" to be made up.
- Asking for an exploded view when you need a cutaway, and vice versa.
Checklist
- The product's composition: CAD, an assembly drawing or a disassembled sample.
- Which assemblies to show.
- Names and labels.
- Where the view will live.
- What to show: composition — exploded view; layout inside — cutaway.
